DESCRIPTION

Space-saving speakers with deep bass and clarity. Ideal for tight spaces. Shop now for fast delivery!

Impeccable In-Wall Custom Install Speaker

  • KEF Uni-Q “Sit Anywhere” technology
  • Ultra-thin bezels
  • Weather-resistant treatment cover
  • Paintable grille and bezel
  • Aluminium dome tweeter with tangerine waveguide

Manufactured country : UK

SPECIFICATIONS
Nominal Impedance

8 Ohm

Sensitivity

87dB (2.83V/ 1m)

Crossover Frequencies

1.7kHz

Frequency Response

110Hz - 24kHz (±6dB) open-backed

Drive Units

LF: 115mm (4.5in.) Dual layer
HF: 25mm (1in.)

Recommended Amplifier Power

10-100W

Product External Dimensions (H x W x D)

Diameter: 222.8 x 222.8 mm (8.77 x 8.77 in.)
Depth: 41mm (1.61 in.)

Cut-Out Dimensions (H x W)

194 x 194 mm (7.64 x 7.64 in.)

Ceiling Thickness (Maximum)

26mm (1.03 in.)

Ceiling Thickness (Minimum)

9mm (0.36 in.)

Mounting Depth From Surface

<36mm (1 7/16 in.)

Optional Rough In Frame

RIF160S

Optional Rear Enclosure

RNC160S

Net Weight

1.05kg (2.31lbs)

Unit Measurement

Piece
